DD Audio Redline 600 Series subwoofer installation in Melbourne by Explicit Customs

DD Audio REDLINE 600 Series Subwoofers

LIKE A BOSS

Categories: , , , Tags:
Description

The 600 Series is a great entry point for a higher performance system design that keeps the vehicle as close to stock as possible. The 600 Series will perform like a boss on as little as 300-600 Watts per, meaning even multiple woofer systems can be driven with one moderate powered amplifier. This keeps electrical upgrades minimal with less added strain on the vehicle. It has a high energy, double stack motor paired with a laminated triple layer poly cotton spider suspension. The 600 Series works best with vented and multi-order enclosures.

600 Series Features:

  • Double Stitched EROM Surrounds
  • High-temp 2.5”, aluminum former voice coil
  • Laminated Spiders
  • Non-pressed paper cones
  • Cooling vent equipped baskets
  • Back plate coil gap venting
  • Extended pole piece
  • Cast Aluminum Basket (608 Only)

SPECS

MODEL 608 610 612 615
Driver Size 8″ 10″ 12″ 15″
Watts RMS 300 – 600 300 – 600 300 – 600 300 – 600
Peak Power 1800 1800 1800 1800
VCD 2.5 2.5 2.5 2.5
Impedance D2 / D4 D2 / D4 D2 / D4 D2 / D4
Piston Dia – in 6 1/2 8 1/2 10 13
Fs – Hz 37.01 36.34 37.68 32.30
Qms 6.707 6.898 6.305 5.941
Qes 0.554 0.471 0.692 0.778
Qts 0.512 0.430 0.624 0.688
Vas – liters 4.502 13.846 25.881 81.609
Xmech – mm 64 64 64 60
Xmax – mm 13 11 13 13
Frame OD – in 8 3/8 10 1/8 12 1/4 15 3/16
Frame OD w/Gasket – in 8 9/16 10 3/8 12 1/2 15 7/16
Mounting Diameter – in 7 3/8 9 1/8 11 1/8 13 7/8
Mounting Depth – in 5 1/2 5 1/2 6 1/16 7 1/16
Motor Diameter – in 6 1/4 6 1/4 6 1/4 6 1/4
Motor Depth – in 2 9/16 2 9/16 2 9/16 2 9/16
Woofer Displacement – cu ft 0.07 0.08 0.09 0.15
Shipping Weight – lbs 17 18 18 21
Sealed Enclosure – cu ft N/A N/A N/A N/A
Ported Enclosure – cu ft 0.75 – 1.25 1.25 – 1.5 1.75 – 2.75 3.0 – 5.0
Price (USD) 189 189 199 229
